General｜Professional CodeCreator CR99 Small Character Inkjet Printer

Product Model｜ CodeCreator CR99

Product Introduction

An advanced inkjet printer equipped with a dual agitator system, specifically designed for heavy pigment inks, ideal for industrial environments.

- +

Add inquiry form Sold out

Product Description

This device is expertly engineered for industrial applications, with a strong emphasis on environmental sustainability and high performance. It combines an easy-to-use intelligent interface with a high-end ink system, delivering a stable and eco-friendly inkjet solution. Designed to meet the demands of heavy pigment inks, the printer features a dual agitator system that ensures uniform ink distribution and consistent output. The built-in ink maintenance functionality allows for optimal performance during prolonged production or intermittent use.

The equipment is tailored for applications that require high-quality printing in industrial settings, boasting the world’s leading capability to print 36 dots of white ink. Its design prioritizes low emissions and minimal solvent consumption, with an integrated solvent recovery system that not only supports environmental standards but also significantly reduces operational costs, providing an efficient and stable solution for industrial manufacturing.

Product Specification

Hardware Specifications

Main Unit Material: Stainless Steel
Main Unit Dimensions (L x W x H): 320 x 320 x 522 mm
Protection Rating: IP54 (upgradeable to IP65)
Printhead Dimensions (L x W x H): 40 x 40 x 186 mm
Print Mode: 5 to 40 dots
Print Height: 5 – 12 mm
Operating Temperature: 5-45°C
Operating Humidity: 10-90% Non-condensing
Power Supply: 80-240V〜50/60 Hz
Display: 7-inch Color Touchscreen
Memory: > 6 MByte, expandable
Connectivity: Printgo, Incremental Encoder 2 Inputs, 2 Outputs (all 24V)

Software Specifications

Interfaces: Ethernet, USB
User Interface: Intuitive graphical user interface
Operating System: Windows CE
Data Transfer: Easy data transfer via USB stick
Production Statistics: Comprehensive production statistics
Ink Management: Easy-to-fill ink and solvent tanks, with an integrated solvent recovery system to reduce consumption and emissions
Printing Applications: Supports text/graphic combinations up to 48 pixels

Additional Features

High-speed printing mode
High machine stability
User-friendly maintenance with four-door access design
Simplified scripting functionality to replace complex applications
Optional dual agitator pigment ink system
