General | CodeCenterC CE100 Small Character Inkjet Printer

Product Model｜ CodeCenterC CE100

Product Introduction

The most comprehensive smart inkjet equipment, easy to operate and maintain, suitable for a variety of application scenarios.

- +

Add inquiry form Sold out

Product Description

This device combines innovation and technology, making it an ideal choice for industrial processes, and is an upgraded version based on the successful predecessor. It features a 10.1-inch color touchscreen that provides a broader operating view and an intuitive user experience, with a simple operation and symbolic design that facilitates user engagement. The intelligent agitation system supports various pigment inks, ensuring stable ink output. The robust design of the CE100 not only enhances the stability of the equipment but also simplifies daily maintenance.

The device includes USB and Ethernet interfaces for easy and immediate data transfer. It supports high-speed printing modes and can combine text and graphics for printing at heights up to 48 pixels. The built-in production statistics feature helps businesses monitor production progress in real time. The equipment is also equipped with a solvent recovery system that effectively reduces solvent consumption and emissions, adhering to environmental standards. The CE100 provides a stable and efficient inkjet solution for various industrial applications, characterized by high reliability and user-friendly maintenance design.

Product Specification

Hardware Specifications

Main Unit Material: Stainless Steel
Main Unit Dimensions (L x W x H): 320 x 320 x 522 mm
Protection Rating: IP54 (upgradeable to IP65)
Printhead Dimensions (L x W x H): 40 x 40 x 186 mm
Print Mode: 5 to 48 dots
Print Height: 5 – 12 mm
Operating Temperature: 5-45°C
Operating Humidity: 10-90% Non-condensing
Power Supply: 80-240V〜50/60 Hz
Display: 10.1-inch Color Touchscreen
Memory: > 300 MByte
Connectivity: Incremental Encoder 8 Inputs, 4 Outputs (all 24V)

Software Specifications

Interfaces: Ethernet, USB, RS232
User Interface: Easy-to-use symbolic operation interface
Operating System: Windows CE
Data Transfer: Easy data transfer via USB stick
Production Statistics: Built-in production statistics feature, capable of combining text/graphics up to 48 pixels
Ink Management: Easy refillable ink and solvent tanks, built-in solvent recovery system to reduce consumption and emissions
Printing Applications: Supports scripting functionality to address complex application needs

Additional Features: High-speed printing mode, high reliability, user-friendly maintenance design, optional pigment printing system with dual agitators
