Specialized Application | Dual-Head Industrial CodeCenter 2 Small Character Inkjet Printer

Product Model｜ CodeCenter 2

Product Introduction

Designed for specialized applications, this dual-head industrial small character inkjet printer offers flexible expansion options and high-performance systems to meet diverse production needs.

- +

Add inquiry form Sold out

Product Description

The CodeCenter 2 is equipped with the capability to expand with a second print head system, allowing users to adjust according to production requirements. The device features an interface identical to that of the CodeCenter, equipped with a 12-inch terminal based on CodeCenter software, supporting independent or synchronized operation of the two print heads. Each print head has its own 3.5-inch maintenance display, which can show the status of the print head and complete operations. By connecting the print heads via a fast internal network, they can operate as a single system, enhancing operational efficiency and convenience. This multi-head system not only increases flexibility on the production line but also significantly boosts production efficiency, enabling marking and coding at multiple locations simultaneously.

Product Specification

Hardware Specifications

Body Material: Stainless Steel
Body Dimensions: 320 x 320 x 626 mm
Protection Rating: IP54
Print Head Dimensions: 40 x 40 x 186 mm
Inkjet Mode: 5 to 48 dots
Inkjet Height: 5 – 12 mm
Operating Temperature: 5-45°C
Operating Humidity: 10-90% (non-condensing)
Power Supply: 80-240V〜50/60 Hz
Display: 12-inch terminal display
Memory: > 15 GB expandable
Connectors: Incremental encoder with 8 inputs and 4 outputs (24V)

Software Specifications

Interfaces: Ethernet, USB, RS232
User Interface: Intuitive graphic-based user interface
Operating System: Windows CE
Data Transfer: Easy data transfer via USB flash drive
Production Statistics: Comprehensive production statistics
Ink Management: Easy-to-fill 1-liter ink tank
Inkjet Applications: Up to 48 dots for text/graphics combination

Other Features

Supports high-speed inkjet mode, script functionality for complex applications, and high machine stability.
