Handheld Laser Printing Machine - Advanced Model (Battery Version)

Product Model｜ LD20i-BIII

Product Introduction

Designed to be lightweight, portable, stable, and efficient, this device meets industrial-grade high-resolution marking needs. It is suitable for various materials such as metal, hard plastic, and glass, and supports a wide range of marking content including Chinese, English, barcodes, QR codes, and logos.

- +

Add inquiry form Sold out

Product Description

An industrial solution for diverse marking needs, suitable for food, electronic components, asset management, and anti-counterfeiting marks. The device offers 50x50mm and 100x100mm marking range options, equipped with a self-developed operating system and a 5-inch touch screen, which is intuitive and easy to use. Its intelligent red light positioning system ensures precise marking, supporting various marking content formats (such as PLT, BMP, PNG, etc.) and allows file import via USB. Featuring a long-life battery (6 Ah), it is particularly suitable for scenarios requiring mobile operations, further enhancing production flexibility and efficiency.

Product Specification

Battery Version (LD20i-BIII)

Performance Data

Laser Type: Fiber Laser Generator
Output Power: ≥20W
Laser Wavelength: 1064nm
Marking Speed: ≤7000mm/s
Maximum Pulse Energy: 0.67mJ
Frequency Adjustable Range: 27-60 kHz

Hardware Specifications

Material: Engineering Plastic
Reflector Size: 10mm
Marking Range: 50x50mm or 100x100mm (optional)
Battery Capacity: 6 Ah
Maximum Power Consumption: ≤150W
Machine Net Weight: 4kg
Control Box Dimensions: 339mm x 160mm x 273mm
Suitable Temperature: 5-40℃
Environment Relative Humidity: ≤85%RH (no condensation)

Software Specifications

Operating System: P9
Supported Marking Content: Text, LOGO, Barcodes, QR codes
Supported Fonts: Simplified and Traditional Chinese, English, Korean, Russian, Arabic numerals, etc.
Supported Image Formats: BMP, PNG, JPG, JPEG, PLT, GIF, PBM
Barcode/QR Code Formats: CODE39, CODE128, EAN13, PDF417, QR, AZTEC, etc.
File Import Method: USB
