Handheld Laser Marking Machine (Power and Battery Version)

Product Model｜ LD20i / 30i / 50i

Product Introduction

This device offers high-resolution and portable design, supporting multilingual text, image, and barcode marking. Widely used in food, electronics, and anti-counterfeiting applications.

- +

Add inquiry form Sold out

Product Description

Designed as a professional marking solution for industrial production, this device offers high precision and versatile marking capabilities, supporting Chinese, English, logos, images, barcodes, and QR codes. It is applicable on various substrates, such as metal, hard plastic, and glass. Equipped with standard 50x50mm and 100x100mm marking areas, it provides flexibility and broad application, suitable for food safety marking, electronic components, asset management, and product anti-counterfeiting needs. This device supports multiple file formats, including PLT, JPG, DXF, and BMP, allowing easy file import via USB, enabling quick setup and operation.

Available in both AC-powered and battery-powered versions, it adapts to various production environments. The AC-powered version is ideal for continuous operation on fixed production lines, while the battery-powered version provides extended battery life for stable use in mobile or specific environments. With an intuitive touch control system and red light positioning, it ensures convenient and precise operation, especially suited for flexible workspaces, enhancing production efficiency and marking quality.

Product Specification

AC-Powered Version (LD20i Ⅱ / LD30i Ⅱ / LD50i Ⅱ)

Performance Data

Laser Type: Fiber Laser Generator
Output Power: ≥20W (LD20i Ⅱ) / ≥30W (LD30i Ⅱ) / ≥50W (LD50i Ⅱ)
Laser Wavelength: 1064nm
Marking Speed: ≤7000mm/s
Maximum Pulse Energy: 0.67mJ (LD20i Ⅱ) / 0.63mJ (LD30i Ⅱ) / 1.1mJ (LD50i Ⅱ)
Frequency Adjustment Range: 27-60 kHz (LD20i Ⅱ) / 40-60 kHz (LD30i Ⅱ) / 45-170 kHz (LD50i Ⅱ)

Hardware Specifications

Material: Engineering Plastic/Aluminum
Reflector Size: Standard 8.5mm
Marking Range: 50mm×50mm (optional) / 100mm×100mm (standard)
Power Supply: 220V
Max Power Consumption: ≤150W/1A (LD20i Ⅱ / LD30i Ⅱ) / ≤350W/2A (LD50i Ⅱ)
Net Weight (Control Box + Handle): 7.7kg (LD20i Ⅱ / LD30i Ⅱ) / 8.6kg (LD50i Ⅱ)
Handle Dimensions: 242mm×79mm×152mm
Control Box Dimensions: 310mm×206mm×307mm

Software Specifications

Operating System: Linux
Supported Marking: Text, Logos, Barcodes, QR Codes
Fonts: Simplified/Traditional Chinese, English, Korean, Russian, Arabic numerals, etc.
Image Formats: PLT, JPG, DXF, BMP
File Import: USB

Battery-Powered Version (LD20i BⅡ / LD30i BⅡ / LD50i BⅡ)

Performance Data

Laser Type: Fiber Laser Generator
Output Power: ≥20W (LD20i BⅡ) / ≥30W (LD30i BⅡ) / ≥50W (LD50i BⅡ)
Laser Wavelength: 1064nm
Marking Speed: ≤7000mm/s
Maximum Pulse Energy: 0.67mJ (LD20i BⅡ) / 0.63mJ (LD30i BⅡ) / 1.1mJ (LD50i BⅡ)
Frequency Adjustment Range: 27-60 kHz (LD20i BⅡ) / 40-60 kHz (LD30i BⅡ) / 45-170 kHz (LD50i BⅡ)

Hardware Specifications

Material: Engineering Plastic/Metal Sheet
Battery Capacity: 12Ah
Battery Usage: 10h 30m (standard) / 2h 50m (continuous)
Charging Time: 4 hours
Net Weight (Control Box + Handle): 9.1kg (LD20i BⅡ / LD30i BⅡ) / 9.8kg (LD50i BⅡ)
Control Box Dimensions: 310mm×206mm×307mm (LD20i BⅡ / LD30i BⅡ) / 310mm×215mm×307mm (LD50i BⅡ)

Software Specifications

Operating System: Linux
Supported Marking: Text, Logos, Barcodes, QR Codes
Fonts: Simplified/Traditional Chinese, English, Korean, Russian, Arabic numerals, etc.
Image Formats: PLT, JPG, DXF, BMP
File Import: USB
