Print Inspection System - Standard

Product Model｜ 2800 / 2801 / 2802

Product Introduction

Equipped with high-resolution CMOS sensors and multi-color LED illumination, suitable for various automated inspection needs. It features robust text reading and detection capabilities, able to identify marks on curved, low contrast, and reflective surfaces. This system is designed for high-performance and precision-demanding industrial environments.

- +

Add inquiry form Sold out

Product Description

Suitable for a variety of industrial applications, such as checking bottle cap seals, detecting package product seal integrity, inspecting printed circuit board (PCB) components, confirming correct insertion of components, and classifying packaging marks. This system is equipped with 1/2.8-inch CMOS monochrome and color sensors, featuring a 6.17 mm diagonal and 2.8 µm square pixel design, supporting up to 2 MP resolution and up to 45 Hz image acquisition frequency. The vision system supports various communication protocols (such as TCP/IP, PROFINET, EtherNet/IP, etc.), easily integrating into existing automation systems.

Product Specification

Including Models 2800, 2801, and 2802

Performance Data

Image Sensor: 1/2.8 inch CMOS, monochrome and color
Resolution:
SVGA1 (720x540) (2800 monochrome only)
1.6 MP (1440x1080) (2801 only)
2 MP (1920x1080) (2802 only)
Electronic Shutter Speed: Minimum exposure 29 μs; maximum exposure 10 ms (internal lighting) / 200 ms (external lighting)
Frame Rate: Up to 45 Hz
Power Consumption: ≤7.5W
Operating Temperature: 0-40 °C
Storage Temperature: -10–60 °C
Operating and Storage Humidity: <95% (non-condensing)
Protection Level: IP67 Certified

Hardware Specifications

Input/Output:
Discrete Input: 2 opto-isolated
Discrete Output: 2 opto-isolated
User-configurable I/O points: 2
Status Indicators: 5 LED indicators and a buzzer
Communication Interface: Ethernet interface
Communication Protocols: TCP/IP, PROFINET, EtherNet/IP™, SLMP, OPC/UA, FTP
Materials: ABS, acrylic, aluminum alloy, silicone, stainless steel, and other durable materials
Weight:
6.2 mm lens: 141 g
16 mm lens: 169 g
Multicolor illumination light: 290 g
Right-angle configuration adds 50 g
Safety Certifications: EU CE, US FCC, TUV CB NRTL IEC 61010
RoHS Certification: Compliant

Software Specifications

Vision Software Suite: In-Sight vision suite
Function Access:
In-Sight EasyBuilder access
In-Sight Spreadsheet access (for 2801 and 2802)
