Laser Fume Extractor

Product Model｜ Fume Extractor A200 & A500

Product Introduction

This system is designed for industrial environments, featuring powerful suction, adjustable airflow, and efficient filtration capabilities. It significantly enhances the cleanliness of the work environment and is suitable for various production applications.

- +

Add inquiry form Sold out

Product Description

We offer two models for you to choose from: A200 and A500. This series of laser fume extractors uses high-efficiency brushless fans, providing stable operation with low noise, making it suitable for work environments requiring clean air. The system features adjustable airflow, allowing users to view airflow settings and operating status in real-time via an LCD display. The filter efficiency reaches up to 99.99%@0.3 microns, and it has a filter clogging alarm function to remind users to replace the filter in a timely manner, maintaining stable performance. This system is suitable for industrial fields such as printing, welding, and electronics manufacturing, and can be used for indoor exhaust without worrying about air pollution.

Product Specification

Performance Data

Specification Item	A200	A500
Maximum Airflow	300 m³/h	500 m³/h
Maximum Negative Pressure	2500Pa	3200Pa
Filtration Efficiency	≥99.99%@ 0.3 microns	≥99.99%@ 0.3 microns
Filtration Precision	≥0.1 microns	≥0.1 microns
Operating Noise	≤55dBA	≤63dBA

Hardware Specifications

Specification Item	A200	A500
Input Power	0.2KW	0.35KW
Voltage Frequency	110V/220V, 50-60HZ	110V/220V, 50-60HZ
Machine Dimensions	250 x 430 x 412mm	360 x 510 x 565mm
Net Weight	15kg	35kg
Interface Diameter	50mm	75mm

Software Specifications

Specification Item	A200	A500
Filter Type	F5 Primary Cotton Filter / F8 Medium Efficiency Filter	F8 Medium Efficiency Filter Bag / H14 High Efficiency Filter
