Fiber Laser Marking Machine

Product Model｜ Fiber 20W、30W、50W

Product Introduction

he fiber laser marking machine features high-speed, high-precision marking capabilities, suitable for processing various materials in industries such as food, cosmetics, hardware, and electronics.

- +

Add inquiry form Sold out

Product Description

Designed for industrial-grade applications, it is equipped with a 720-degree rotating laser head, adaptable to various production line needs. The high-precision beam control allows for detailed marking on high-density materials, maintaining the aesthetics and quality of the products. The independently developed intelligent touch screen control system boasts a stable high-intelligence computing chip, ensuring ease of operation and low failure rate. With marking speeds up to 12000mm/s, it efficiently handles diverse patterns and complex content. The design facilitates easy integration, featuring a high-transparency coated field lens that expands the marking area. The compact and convenient laser head supports high configuration options and connection to traceability systems, enhancing product safety and tracking management.

Product Specification

Performance Data

Power: 20W, 30W, 50W, depending on the selected model
Laser Wavelength: 1064nm
Marking Speed: ≤12000mm/s
Marking Method: High-precision two-dimensional scanning
Marking Range: Standard 110mm×110mm, optional up to 500mm×500mm
Production Line Speed: 0~189m/min (depending on material and marking content)
Language Support: English, Chinese, Korean, Russian, German, Arabic, etc.
Barcode/QR Code Support: CODE39, CODE128, CODE126, QR, Z-Code, DM, Visual code, etc.

Hardware Specifications

Casing Material: Anodized aluminum
Main Controller: 10.1-inch external controller
Cooling System: Air-cooled (water-cooled optional)
Laser Head Dimensions: 303mm x 83mm x 107mm
Controller Dimensions: 300mm x 200mm x 400mm
Positioning Method: Red light positioning and infrared focusing
Reflector Size: Standard 8.5mm
Power Supply: 220V
Maximum Power Consumption: ≤550W
Net Weight: 18kg
Interface: USB2.0 / Photonic Trigger / Synchronizer

Software Specifications

Operating System: Linux P9
Supported File Format: PLT
Marking Types: Dot matrix and vector
